Features

• High frequency and true double - conversion • DSP digital control technology • Input power factor correcon (PFC) • Wide input voltage range • Output power factor 1.0 • Cold start • Auto sensing frequency • ECO mode operaon for energy saving • Selectable output voltage via LCD • Output bypass seable for 1,2,3 KVA via LCD • 50Hz/60Hz frequency conversion mode available on 6 ~ 10 KVA • 6 ~ 10 KVA built in output isolaon transformer • Selectable baery low voltage via LCD • Power - on self test • Advanced baery mangement (ABM) • Short circuit and overload proteccion • Automac charging in OFF mode • Fan speed auto control when loads varies • Standard RS232 communicaon port and Rj45 protecon • Optional USB/SNMP communicaon port • Optional emergency power off (EPO) • Optional extension baery bank • Optional manual bypass on 6 - 10 KVA • Optional N+X redundancy parallel on 6 - 10 KVA

Download Catalog

Features

• High frequency and true double - conversion • DSP digital control technology • Input power factor correcon (PFC) • Wide input voltage range (110 V ~ 300V) • Output power factor 1.0 • Cold start • Auto sensing frequency • ECO mode operaon for energy saving • Selectable output voltage via LCD • 50Hz/60Hz frequency conversion mode available • Selectable baery low voltage via LCD • Power - on self test • Advanced baery mangement (ABM) • Short circuit and overload proteccion • Automac charging in OFF mode • Fan speed auto control when loads varies • Standard RS232 communicaon port • Optional USB/SNMP communicaon port • Optional emergency power off (EPO) • Optional extension baery bank • Optional manual bypass • Optional N+X redundancy parallel

Download Catalog

Features

· High frequency online double – conversion with DSP control · Modular design high reliability easy maintenance · Input power factor correcon (PFC) · ECO mode operaon for energy saving · Input voltage range 60 -160 Vac; autosensing 50 / 60 Hz frequency · Support two modes of frequency conversion: 50Hz input / 60 Hz output and 60Hz input / 50 Hz output · Input power factor > 0.99; Input THDi ≤ 3%; output THDv ≤ 3% · Output power factor: 1.0 · High efficiency: load > 15%, efficiency ≥ 90%, load > 50%, efficiency ≥ 96% · Share baery pack in parallel operaon or separate baery pack for different UPS · Flexible charge parameter and baery configuraon seng, selectable baery number: 16 pcs / 18 pcs / 20 pcs · Advanced intelligent baery management technique, prolong the working life of de baery effecvely · Support baery cold start and mains supply self – starng · 5.7 inches LCD touch screen, friendly human and machine interface · Complete hardware and soware protecon funcon, robust self – diagnosc funcon, and abundant even log to check · Perfect password control technology, including the first power - on password control and maintenance password control · Reminders of baery out of warranty · Standard emergency power off (EPO) · Standard RS 232, USB, RS 485, dry contacts communication port · Optional SNMP communicaon port · Optional N+X redundancy parallel up to 8 Units · Optional built - in isolation transformer · Optional batery temperature compensation

Download Catalog
